Desktop Robotic PCB Iron Soldering Machine With Multi Axis

Name: Desktop Robotic PCB Iron Soldering Machine With Multi Axis
Brand: Winsmart
Price: 1 USD

Brand Name : Winsmart

Model Number : SMTSR123

Certification : CE

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 300 sets per month

Delivery Time : 5-8 days

Packaging Details : Plywood case

Warranty : 12 months

Soldering tip : 2

Fixture : Customized

Power : 220/110V

Working Stroke : Customizable

Name : PCB Iron Soldering Machine

Contact Now

Automatic Multi Axis Desktop Robotic PCB Iron Soldering Machine

PCB Iron Soldering Machine Features:

・ Suitable for different products, welding temperature can be set freely (each welding point can be set different temperature)
・ Welding components can be adjusted and buffered in various directions to ensure that the welding original and PCB are not damaged.
・ Temperature control (still air state ± 1C)
・ A digital pressure gauge is provided to prevent the pressure from exceeding the pressure range.
・ During the use of the welding head, the heating and cooling are fast, the heat transfer coefficient is good, and the wear
resistance is good.

PCB Iron Soldering Machine Parameters:

Model	SMTSR123
Dimension	680500720mm
Weight	80Kg
Control	PLC
Programming	Teaching box
Driving mode	Stepper motor
Stroke	400(X)x300(Y1)x300(Y2)x80(Z)
Soldering head	2
Repeatability	±0.02mm(X/Y/Z)
Temp. Range	0-550℃
Solder Wire Spec	￠0.3-1.6mm
Number of axes	4
Working pressure	0.4~0.6Mpa(No water mist)
Power	AC110V/220V 300W
Display	LCD

PCB Iron Soldering Machine Application:

Desktop Robotic PCB Iron Soldering Machine With Multi Axis
