FR4 PCB Punching Machine , CNC Routing Machine For PCB Depanelization

  • 1
  • 2

Brand Name : Winsamrt

Model Number : SMTP300

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : USD1-10000/set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 sets

Delivery Time : 7-15 days

Packaging Details : Plywood case

Output : 8T

PCB Material : FR4 PCB

CE Certificate : Yes

Packaging : Plywood Case

Mold Processing : Wire-cut

Name : PCB Punching Machine

Contact Now

FR4 PCB Punching Machine PCB Punching Mold For PCB Depanelization

Function:

It is designed for PCB/FPC which is connected by points and stamp holes, has high efficiency precision stamping and punching effect. It is only guarantee slitting FPC, PCB deformation in current market.

Its minimum cutting precision is ±0.05mm for special slim PCBs. Max working area is 460*320mm.

PCB Punching Machine Specification:

Working area 460*320mm　
Working pressure 0.45-0.7Mpa
Cutting precision ±0.05mm
Cycle time 7-15 seconds
Output 8T
PCB/FPC thickness 0.08-3.5MM
PCB/FPC material FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode Punching
Punch fixture Die tooling(mold)
Working Property

LCD display, Automatically records the number of

processed products, automatic punching
Transmission port International standard
Operation Language English
Stroke 50MM
Mold height 170MM
Power 380/220V
Fuse 3A
Machine dimension 820x740x1750mm
Machine weight 680kgs

PCB Punching Machine Features:

1. Depaneling PCB/FPC by means of punching dies, to avoid micro-cracks caused by manual.

2. Die toolings is changeable

3. Easy set up of punching dies

4. Loading and unloading PCBs is convenient

5. Easy operation, has safe protection system

6. Air cylinder driven

PCB Punching Machine Details:

FR4 PCB Punching Machine , CNC Routing Machine For PCB DepanelizationFR4 PCB Punching Machine , CNC Routing Machine For PCB DepanelizationFR4 PCB Punching Machine , CNC Routing Machine For PCB Depanelization

PCB Punching Machine Delivery Terms:

1. Ex-work/FOB/CIF/DDU, up to clients

2. Production leadtime: 7-15 days to customized make die tooling and test it with the punching machine.
